Icons

Descriptions

Object required

ON_DISP

Commands reflected in the display

Requirement

Not executable

Commands executed by touch operation

Requirement

Executable

Commands specified in ‘input.txt’ and
specified within command

Unnecessary

-----

Command description contents

Description

l Notes

Description example

Objects created with Tomate are appended with the following properties:

*1  Only display objects that define ‘dsp{}‘ / ‘img{}‘ / ‘bar{}‘

*2  Only display objects that define ‘bar{ }’ / ‘dsp{ }’

l    Property ‘P’ is a long press time with a positive value and a repeat time with a negative value.

See ‘pro{ }’ command for an example.

[Variable ]

Display the value of a variable in an object.

[variable ]    Show variable contents in target shape object

l    Enclose in [ ]

l    Variable names must be set in TOMATE's variable list

l    It is displayed in the font specified in the TOMATE app.

[num]   Display the contents of the variable name ‘num‘ in an object.

( Formula : Lower|[ V], Upper|[ V] )

Calculate an expression enclosed in parentheses ().

Formula                  Formula‘s format is ‘(Variable) (Expression) (Value) ‘

(Variable)           Variable name  * The ‘[ ] ‘ is not required.

(Expression)        Substitution and Calculation are assigned from the right side to the left side.

                               Comparison gives a true (=1) or false (=0) results of the left and right sides.

(Value)                numeric value or [variable]  * ‘[]’ is required for variable

Lower| [V]             Lower limit of the lower value. [Variable] is also allowed. (optional)

Upper| [V]             Upper limit of upper value. [variable] is also allowed. (optional)
If the value is a string, the maximum number of characters is used.

                                   * Operation when only one Lower or Upper is specified

l  Enclose arithmetic expressions in parentheses ().

l  Operations are only assignment operations.

l  When the variable and the value are ‘numeric’, it becomes a numerical operation.

l  The display of the decimal point depends on the number of decimal places of the used variable or real number.

l  Rounding less than the displayed value is round to even numbers.
(If there is no decimal point, an even number + 0.5 is ‘rounded down’ and an odd number + 0.5 is ‘rounded up’)

l  Numeric values are treated as strings by enclosing them in single quotation marks(').

l  If either is a ‘character string‘, the character string is added or deleted.
(*=, /=, %= are not allowed in strings)

l  In the case of comparison, '1' or '0' is the return value, and in the case of assignment/operation, the variable content on the left side is the return value.

l  In the case of >, >=, <, <= comparison, they are converted to floating point type and compared.
== and != are compared as strings.

(var = 100)                 Assign 10 0 to [var]

(var += [x]:0,3)           var=var+ value of [x] (If the upper limit exceeds 3, it loops to 0)

(var += 1:10)               var=var+1 (10 or higher holds to 10)

(var -= 1:0)                 var=var-1 (0 or lower holds to 0)

(var -= 10:[a],[b])     var=var-10 ([a] and [b] below)

(str = AB)                    str is the string ‘AB‘

(str+=C)                       Add ‘C‘ to the end of the string str

(str -= 2)                     Remove two characters from the end of str

(num += '2')                Add ‘2’ as a string to the end of [num]

(str -= ' ')                      Delete one character from the end of [str] (characters within ' ' are ignored)

(str += 'A':10)              Add the character 'A' to the end of [str] (11 characters or more cannot be added)

if{ (a > 10) : (a=0) }                  If variable [a] exceeds 10, set it to 0.

if{ (str==OK) : <@next> }      If variable [str] is ‘OK’, go to next page.

<page |  [V] : 1 >

Go to the specified page.

<page>                Go to page name page (variable is also acceptable)

<@next>              Move to next page (page order in TOMATE)

<@prev>            Previous page move (page order in TOMATE)

<@back>            Back to the previous page

<page:1>            Display page on top of current page (currently page is page)

<@get>               Get the current page name (output the current page name to output.txt)

l  Enclose the page specification within ‘< >’.

l  When an object with a page navigation command is touched, the specified page will be displayed.

l  When the page is navigated to, the script written in the page's “ON_DISP” will be executed.

l  The <@get> command is applicable from version 1.03 onwards.

When Tomate is specified in page name order ‘1‘, ‘2‘, ‘3‘

<1>                             Go to page ‘1‘

<@Next>                 Go to next page ‘2‘

<3:1>                         The current ‘2‘ page is overlaid with the page ‘3‘

<@prev>                 Show page ‘2‘ before ‘3‘

<@back>                  Show page ‘3‘ immediately preceding (do not overlap the current page)

<[page]>                   Go to page name stored in variable the [page]

<@get>                     The current page name is output to output.txt enclosed in '< >'
                                       (if the current page name is '1', it will be output as '<1>')

bar{ [V] : Max |[ V] : H| V }

Show a progress bar.

[V]                Variable name to store progress value (required)

Max| [V]      Maximum value variable allowed (minimum value is fixed 0)

H| V             Progress bar orientation (optional)

                         'H' = Progress in landscape orientation (left to right)

                'V' = Progress in portrait orientation (bottom to up)

l If the orientation is omitted, it is in landscape orientation.

l The size, position, and color of the bars reflect the content specified in the Tomate tool.

bar{ [i] : 100 }

Display a horizontal progress bar corresponding to the value of [i] as an upper limit of 100

bar{num : 255 : V}

As the upper limit of 255, display a vertical progress bar corresponding to the value of [num]

bgm{ file | No | [V], cmd : volume }

Sounds BGM from the BGM registration list and file name.

File                File name that exists in current folder.
                           Raspberry Pi : ‘home/user/Tomate/’
                           Windows:  Where the ‘project-name.exe’ is.

No                Or BGM list number registered in Tomate or [variable]

cmd               0=Stop, 1~99=Playback number of times, -1=Continuous loop playback,
                         100 or more = Fade out stop (value is fade time (x1ms))

Volume        Set volume 0~100 (optional)

l  The sound formats that can be used are ".wav", ".mp3", and ".mid".

l  When ‘cmd‘ is omitted, BGM is played once.

l  The specified number of times of reproduction is from 3 times.
(If 2 is specified, it will be played only once)

l  Volume is the volume relative to the current system volume. (If system volume = 80%, specified volume = 50%, the playback volume will be 40% of the system volume)

l  If a new playback command is issued during music playback, the previous music will be interrupted and played.

l  If Volume is omitted, the system will play at the current volume.

l  ‘file | No | [V]’ is ignored during stop command (cmd=0).

bgm{ 1,-1 : 50 }

Loop playback of the first sound source in the sound source list at 50% volume

bgm{ sound.mp3, 1 }

Play ‘sound.mp3‘ in current folder once at current volume

bgm{ 1 , 3000 }

Stop the currently playing BGM fade out in 3 seconds

brt{ Value | [V] : @get }

Set the brightness of the backlight

Value| [V]          Brightness 0~255 or [variable]

@get                   Get current brightness (optional)

l  Anything outside the range and non-numeric values are ignored.

l  If ’@get’ is specified, a variable must be specified.

l  Enter the ‘brt{ }’ command during sleep to wake up.

l  The setting value is stored in the current path.

brt{ 50 }

Set brightness to 50

brt{ [V] }

Set the luminance to the value of the variable [V]

brt{ [V] : @get }

Get the current luminance in variable [V]

  brt{ }

Wake at current brightness on sleep.

ckb{ [var ] : strings : mark0, mark1 }

Show checkboxes.

[var]             A variable that stores the check value

strings        Strings to display

mark0        Uncheck Mark character (optional)

mark1        Mark character with check (optional)

l  Display a checkbox to the left of the strings, and when clicking the object, the box switches the checking.

l  The variable is ‘1’ in checking, ‘0’ in un-checking.

l Checkbox character
Unchecked (var=0)   ◻ (Unicode: 25A1)
Checked (var!=0)     ☑ (Unicode: 2611)

l The checkbox depends on the font style.

ckb{ [var] : }

   Display check box only.

ckb{ [var] : Options }

          Display ‘☑ Options’ on the object and change the value with clicking.

ckb{ [var] : Do not display from next time: -, + }

  "- Do not display from next time" is displayed, and when touched, it changes to ‘+’.

ckb{ [var] : : OFF, O N }

  Displays "OFF" or "ON" according to the value of the variable [var]

cmd{ cmd1 : cmd2 : ... : cmdN   }

Run commands in bulk.

cmd1                    1st command

cmd2                    2nd command

cmdN                    Nth command

l Commands separated by colons e:f

cmd{ (a+=1) : (b+=1) : (c-=10) : (d*=10) }

Combine arithmetic expressions in bulk

if{ (V==0) : cmd{ (a+=1) : (b+=1)} : cmd{ (c=10) : (d=10) } }

    Example of combining commands in a batch with an if statement

dsp{ [var] : N=strN, fcolN, bcolN : ...  }

Display text in the specified color scheme.

The display is the same as the value specified in the variable.

[var]                         A variable that stores the value

N                              Corresponding value (else in ‘E‘ or ‘e‘)

strN                        Corresponding display string (Variables can be specified)

fcolN                      Text color (optional)

bcolN                    background color (optional)

l Display the string s tr corresponding to the value of the var variable in the object specified by Tomate in the specified color of ‘fcolN‘ and ‘bcolN‘.

l Color notation can be in RGB color number #000000 ~ #FFFFFF format or color name notation such as ‘black‘, ‘white‘, ‘blue‘, etc.

l If the text color and background color are omitted, it depends on the drawing object.

l You can specify variables enclosed in [ ] in the display string. (Ver1.01 and later)

dsp{ [val] : E=Kuro, black : 1=Aka, red : 2=Ao, blue : 3=Shiro : white, gray }

     When val=1, ‘Aka‘ is displayed in red letters, when val=2 is displayed as ‘Ao‘ in blue letters, when val=3, ‘Shiro‘ is displayed in White letters on an ash background, and otherwise ‘Kuro‘ is displayed in black letters.

dsp{ [val] : e=ITEM0,#000000,#FFFFFF : 1=ITEM1,#FFFFFF,#FF0000 : 2=ITEM3,#FFFFFF,#0080FF }

Example of specifying the color notation with RGB number

dsp{ [gender] : male=Mr. George, female= Ms. Mary }

Example in case of the variable is not number.

dsp{ [i] : 0=[name1] : 1=[name2], white, red : e=[name3], white, red }

     Example of specifying a variable in the display string

if{ (formula ) : True-cmd : False-cmd }

Branch processing is performed based on the result of comparison operation.

(formula)      Right-hand side [comparison expression ==, !=, >, <, >=, <=]

                          Multiple comparison expressions include &(and), | (or) can be used

True-cmd   When the comparison is true, the command to be executed

False-cmd   When the comparison is false, the command to be executed (Optional)

l The comparative expression is of the form of only two terms
(Left-hand side [expression] right-hand side).

l The left-hand side is variable only, and the variable symbol [ ] can be omitted.

l The variable [ ] on the right side is necessary.
(If omitted, it will be treated as a character string.)

l In the case of >, >=, <, <= comparison, they are converted to floating point type and compared.
== and != are compared as strings.

if{ (var==1) : <@next> }

if{ (var==1) : msg{Var is true} : msg{Var is false} }

if{ (v1<[v2] & v3<[v4]) : msg{ It is true. } : msg{ It is false. } }

if{ (V1>=[V2] | V3>=[V4] | V5>=[V6]) : msg{ TRUE. } : msg{ FALSE. } }

int{ time : cmd }

Perform processing at specified time intervals.

time      interval time (x1ms)

cmd      command

l  Only one interval operation is performed in all screens.

l  Interval processing stops when the page switches.

int{ 1000 : (tm+=1) }

+1 the variable [tm] at 1 second intervals

img{ file |  list-No |  [V] | (f)  }

Display the specified image in the frame range of the drawing object.

file                 File name that exists in current folder.
                           Raspberry Pi : ‘home/user/Tomate/’
                           Windows:  Where the ‘project-name.exe’ file is.

list-No        Or the image number registered in Tomate's image list

[V]| (f)       Or [variable] (arithmetic expression)

l The size of the image is automatically scaled to the W,H ratio of the object frame, keeping the ratio of the original image.

img{ image.jpg }

          Display the image of ‘image.jpg’ in the object frame.

img{1}

          Display the first image of the registered image list in the object frame.

img{ [num] }

          Display the variable [num]-th image in the registered image list in the object frame.

msg{ Message : Btn1=Cmd1, Btn2=Cmd2, Btn3=Cmd3 : @wait =millisecond }

Display a message box.

Message                 To display messages

Btn1~3                    Characters to display in button # (optional)

Cmd 1~3                Command to execute when button # is pressed (optional)

@wait                    Time to auto-erase message box in x1ms (optional)

l Message statements can be newline with ‘\n‘ (ASCII:0x5C,0x6E) character.

l If ‘Cmd#‘ is omitted, only the button is displayed.

l If ‘Btn#‘ is omitted, the OK button is automatically added.

l Omitting ‘Btn#‘ when ‘@wait‘ is specified hides the button.

l When the button is pressed, the message box is closed.

msg{ Changed settings. }

with the OK button automatically

msg{ Are you sure to delete the file? : OK=”REMOVE” , Cancel }

Press OK to output the ‘REMOVE‘ string to ‘output .txt‘.

msg{ password is different. : @wait=3000 }
Displays a message and automatically erases after 3000ms (3 seconds)

out{ strings | [V] | @clr }

“strings”

Outputs the specified character string to [output.txt].

Strings                  Prints the specified string

[V]                         Output variable contents

@clr                       Clear output.txt contents

l  If it is a fixed string, it may be simply enclosed in double quotation marks (“).

l  When written in Script, the specified string is written to output.txt each time the corresponding object is touched.

l  This character string can be read by a user program or the like to determine which object is being touched.

“Hello”                        Added ‘Hello’ to output.txt.

out{ [var] }                 Append the contents of the variable [var] to output.txt.

out{ @clr }                 Clear the contents of output.txt.

[var] : pad{Title, Min, Max, Digit : Cmd }

pad{ [var] : Title, Min, Max, Digit : Cmd }

Display a keypad for entering numbers and letters.

[var]          Name of the variable to be set
                       (value is displayed when written outside, hidden when written inside)

Title           Messages to display on the Title keypad

Min          Minimum value if set to numeric (optional)

Max         Maximum value when set to numeric value (optional)

Digit        Maximum number of digits that can be entered,
                            including decimal point and sign (optional)

Cmd            Command to run after setting the value (optional)

l When Min, Max is set, the string of ‘Min ~ Max‘ value is added to ‘Title‘.

l If Min and Max are omitted, it becomes a character string. (Can be used for IP and TEL)

l When there is only one ‘Min‘, ‘Max‘, or ‘Digit‘ item, ‘Digit‘ is specified.

l If ‘Min‘ and ‘Max‘ is specified, the enterable decimal places are the decimal places of ‘Min‘.

l If ‘Digit‘ is set and there is more input than the specified digits, the input will not be accepted.

l If Min, Max and Digit are not specified, the maximum input digits will be 16 digits.

[num] : pad{enter a number,0,9999 : msg{ numeric. } }

Display the keypad, assign the entered value 0~9999 to the variable num and display the value on the object. Display message after confirming input.

  [num] : pad{ Input value : 0.001, 9999, 5 }

    Accepts input up to 5 digits including the decimal point in the range of 0.001 to 9999.

pad{ [str] : Enter IP address, 15 }

Display the keypad, assign the entered 15-digit value as a string to the variable [str], but the value is not displayed on the object. (In the case of a character string specification, multiple periods and hyphens can be entered.)

pro{ page, ID, prop, val | [V]| (f) : @get}

Change the properties of an object.

page                        Name (only '@' mark for current page)

ID                            Object ID in the page

prop                       Object properties (X, Y, W, H, V, B, P, LC, PC, Script)

value| [V]|(f)        Property value or variable or comparison operation expression

@get                      Get the current contents to variable [V]

l Calculation expressions are True='1', False='0', which is limited only to comparison expressions (arithmetic expressions such as +=, -=, etc. are always true)

pro{ page1, IMG_001, V, 0 }

Set the 0 (erase) to the V (visible) of the ID gIMG_001h in page1

pro{ @, BOX, V, (val==0) }

Set the result of (val==0) to the ID ‘BOX’ object display of the current page

pwd{ [var ] | pass : Title | @setup : Cmd1 : Cmd2 }

Display a keypad for entering passwords.

[var] | pass         A variable that contains the password or password value

Title | @setup    Messages to display on the Title keypad, or setup the password.

Cmd1                    Command to run on match

Cmd2                    Command to run on mismatch

l Setting ‘Title‘ to ‘@setup‘ sets a password, and you can set it by entering the password twice. (Password setting is required for variables)

l In the Title column in the password setting, the PWD1 and PWD2 messages registered in "Keypad" of "Parts Edit" are displayed for the first and second times.

l The maximum number of digits that can be entered for a password is 16 characters.

pwd{ [pass] : Enter password : <@next> : msg{ Wrong code! } }

The entered value matches the value of the variable [pass] on the next page, and the message is displayed when there is a mismatch.

pwd{ 1234 : Enter the code : <page> : snd{4} }

The value entered is 1234 and the page moves in the match, the sound rings in the mismatch.

[Example of password change]

pwd{ [pass] : @setup : msg{ password changed. } : msg{ Please try again. }}

Enter the password twice, and if the two match, store it in the variable the [pass].

rnd{ [V] : min, max : seed }

Generate random numbers.

[V]            Variable to store random numbers

min           Lower bound of random numbers

max           Maximum upper bound of random numbers

l  Once the seed value is set, the random numbers generated thereafter will be based on the set seed value.

rnd{ [num] : 1, 1000 }

Generate random numbers in the range of 1~1000 and store them in [num]

rnd{ [num] : 1, 1000 : 365 }

In the range of 1 ~ 1000, generate a random number with a seed value of 365 and store it in [num]

[val] :  sel{ Title : n0=dsp0, n1=dsp1 , ... : Cmd  }

sel{ [val] :Title : n0=dsp0, n1= dsp1, ... : Cmd  }

Show a selector tool to select an item.

[var]           A variable that stores the value of the selected item
                     (Item name is displayed when written outside, hidden when written inside)

Title            Messages to display on the Selector parts

n# =           Value of item # (optional)

dsp#          Item# display name

Cmd            Command to execute after selection (optional)

l  When a DSP string is displayed in the item field of the selector and selected, the item number is stored in the variable [var].

l  When a variable is written outside the command, the display name corresponding to the value is displayed.

l  The value corresponding to the display name can be either a numerical value or a character string.

l  If the number of items exceeds the number of items displayed on one page of the selector, a page switching button is automatically displayed on the selector.

l  If the item number is omitted, a sequence number of 0~ is automatically added.

l  If the selection is canceled (by touching outside the frame), the command will not be executed.

[var] : sel{ Select region : 0=Other, 1=Northeast, 2=Midwest, 3=South, 4=West }

The target object displays the name of the selected region, and var stores the number.

sel{ [var] : Select gender :Other, Male, Female }

The number selected as 0=Other, 1=Male, 2=Female is stored in [var].
The object does not display a gender.

sel{ [x] : Select value : 1,2,3,4,5 : <@next> }

1, 2, 3, 4, and 5 are displayed as options, and when selected, the page moves to the next page. When an item is selected, 0 to 4 will be stored in the variable [x].

slp{ Second | [V] : @get }

Set the automatic off-time of the backlight when inoperative

Second| [V]       Auto-off time (seconds) or [variable]

@get                   Get the current setting value to [Variable]

l  Anything other than a number is ignored.

l  It lights up when you touch the screen when the light is turned off automatically.

l  If ‘@get’ is specified, a variable must be specified.

l  The setting value is stored in the current path.

slp{ 900 }

Set the auto-off time to 15 minutes.
 slp{ [V] }

Set the automatic light off time to the value of variable [V].
 slp{ [V] : @get }

Stores the current off setting time in variable [V].

snd{ file | No | [V], loop : volume }

Play sound effects from the sound effect registration list or file name.

File                        File name that exists in current folder.
                                         Raspberry Pi : ‘home/user/Tomate/’
                                         Windows:  Where the ‘project-name.exe’ file is.

No or [V]              Tomate registered sound source list number or [variable]

loop                     Loop count 0~10 (optional)

volume               Volume 0~100 (Optional)

l  The only sound format that can be used is ‘.wav’ format.
(".mp3" can also be used when running on Windows)

l  If loop is omitted, it is played once.

l  If loop is set to 0, the sound effect stops playing.

l  Volume is the volume relative to the current system volume. (If system volume = 80%, specified volume = 50%, the playback volume will be 40% of the system volume)

l  If Volume is omitted, it will be played at the current system volume.

snd{ 1 }

Play the first sound source in the sound source list once (volume is the current value)

snd{ beep.wav, 2 : 100 }

Ring the ‘beep.wav’ in current folder twice at 100% volume

swi{ [var]|(f) : V=cmd : … : VN=cmdN : @=dflt }

Compare with the value of the variable var and branch to switch or case.

           [var]|(f)           Variable or expression that stores the value to be compared

           V=                      Comparison value such as a number or string (constants only) (optional)

           cmd                   Command or expression when matched

              @=dflt              Command when default is specified (optional)

l  Executes the command whose comparison value matches the variable [var].

l  The comparison value ‘V=’ can be omitted. If omitted, a consecutive number starting from 0 will be automatically assigned.

l  The comparison value can be either a number or a string.

l  Compatible with TOMATE v1.02.0 and later

swi{ [i] : 1=(str=’A’) : 2=(str=’B’) : 3=(str=’C’) : @=(str=’ ‘) }

When the content of variable i is 1, A is stored in variable str, when it is 2, when it is 3, C is stored in variable str otherwise blank is stored.

swi{ [i] : @=(str=’ ‘) : (str=’A’) : (str=’B’) : (str=’C’) }

The above comparison value is omitted. @= is 0 or other, and a consecutive number from 1 is specified.

swi{ (s) : Spring=(i=4) : Summer=(i=7) : Autumn=(i=9) : Winter=(i=11) }

When the content of variable s is the corresponding string, the value is set to variable i.

tim{ format }

Display a clock on an object.

Format           edy/mo/yr  hr:mi:scf etc.

                        yr         AD Year

                        mo      Month

                        dy        Day

                        hr         Time

                        mi         Minute

                        sc         Seconds

l  The clock is displayed on the object drawn in Tomate application.

l  Strings such as ‘yr’, ‘mo’, and ’dy’ are replaced with values from the built-in clock

l  The date is zero-suppressed, and the time is zero-padding.

tim{ mo / dy / yr  hr : mi : sc }

Western calendar, date and time display as g09 / 05 / 2022 12 : 34 : 56h

tim{ hr : mi : sc }

Show clock time only

var{ V1, V2, EEE , Vn : Flag }

Prints the contents of the specified variable to ‘output.txt’.

V1            1st variable name

V2            2nd variable name

Vn            n variable name

Flag         If h:flagh is specified, output with ‘variable name=’ (optional)

l Separated by commas, multiple variables can be specified together.

l The contents of the specified variables are printed to output.txt, enclosed in { } and separated by commas, in the order specified.

l String newlines are appended as string ‘\n’.

l The “:Flag” specification only requires a colon and string, and the contents of Flag are ignored.

var{ a, b, msg, str }

Return value (output.txt) à { 10, 5, Hello!\nWorld, Apple }

var{ a, b, msg, str :1 }

Return value (output.txt) à { a=10, b=5, msg=Hello!\nWorld, str=Apple }

vol{ Value | [V] : @get }

Set the system volume

Value| [V]          Set volume to 0~100 or [Variable]

@get                   Store the current volume in variable [V] (optional)

l  The ‘snd{}’, ‘bgm{}‘ commands are played based on this volume.

l  The volume cannot be changed during playback.

l  If ‘@get’ is specified, a variable must be specified.

l  The setting value is stored in the current path.

vol{ 50 }

          Set volume to 50%

vol{ [V] }

          Set the volume to the value of the variable [V]

vol{ [V] : @get }

          Store the currently set volume to [V]
